Automatic Brick Making Machine

This fully automatic brick making machine can produce high-quality concrete bricks, hollow blocks, and paving blocks.
Recommended site area:≥1000 Square meters
Pallet size: 900 x 550mm
Equipped with mixer model: JS500 mixer
Working principle: hydraulic and vibration forming
Loading container specifications and quantity: 1 x 40HC

Send Inquiry

Product Introduction

This fully automatic brick making machine uses a PLC control system to automatically mix and process these raw materials into high-quality concrete bricks, hollow blocks, and paving blocks, tiles, and other construction products. Flexible mold changeover system to accommodate different block sizes.

automatic-fly-ash-brick-making-machine

Technical Parameters

Model	YG4-15S
Overall Dimension	5900x 2200 x2400mm
Rated pressure	16MPa
Vibration frequency	2800-5100(r/min)
Pallet Size	900 x 550mm
Molding Cycle	15-20(s)
Excitation force	50KN
Overall power	21.75KW

Main Capacity

Type of brick	Size	Molding Cycle	Output per hour
Clay brick	200x100x60mm	18-23s	2200-2800 pcs/h
Solid brick	240x115x53mm	15-17s	5082-5760 pcs/h
Hollow block	390x190x190mm	15-20s	720-960 pcs/h

Materials

Raw materials for making bricks: cement, sand, aggregate, fly ash and chemical admixture.

Features

This fully automatic brick forming machine adopts tabletop vibration pressure forming and a reciprocating guide feeding device. It has a short forming cycle, high production efficiency, dense block quality, high strength, and precise dimensions.
One machine for multiple purposes: By changing the brick machine mold, it can produce different specifications of porous bricks, hollow blocks, curb stones, pavement bricks, grass planting bricks, slope protection bricks and other cement products.
This brick making machine is suitable for large brick factories or developers. The machine is equipped with PLC touch screen, so it has a relatively high degree of automation, stable performance, and easy operation and maintenance.
The German Bosch pneumatic vibration reduction system greatly reduces the noise during vibration and the adverse effects of vibration on the equipment, making the equipment more stable and reliable.

Brick Sample

paver-block-machine

FAQ

Q: Can the machine produce different block sizes?

A: Yes, YG Machinery's hollow block making machines are equipped with adjustable molds, allowing for the production of various block sizes to meet diverse construction requirements.

Q: How long is the warranty period for the machines?

A: YG Machinery offers a comprehensive warranty period, typically ranging from 12 to 24 months, depending on the specific machine model and terms of purchase. With its reliable products, competitive pricing, and comprehensive support services, YG Machinery stands as a trusted partner for construction professionals seeking efficient and cost-effective hollow block making solutions.

Q: How does an automatic brick making machine work?

A: Material Feeding > Mixing and Molding > Pressing and Compaction > Ejection and Stacking.
