Water Drilling Machine
Water drilling machines, also known as water well drilling rigs, are specialized equipment used to create boreholes for accessing groundwater. These machines come in various sizes and configurations, suitable for different applications such as agricultural irrigation, geothermal drilling, and residential water supply.
Henan Yugong Machinery Co., Ltd.: Your Professional Water Drilling Machine Manufacturer!
Henan Yugong Machinery Co., Ltd., established in 2005, established its own production factory in Shandong and began to produce and sell products such as earthmoving machinery, concrete machinery, and lifting machinery. The company's main products include excavator attachments, electric mini skid steer loader, forklift, ready mix concrete truck, wall cutting machine, rock breaking tools, water drilling machine, rotary piling machine, etc.
Why choose us?
Quality services
YG Machinery takes customer satisfaction as its core. We not only provide high-quality machinery and equipment, but also provide comprehensive pre-sales consultation, in-sales support and after-sales services to ensure that customers receive an excellent experience throughout the entire purchase and use process.
Quality assurance
Our factory facilities and equipment are carefully designed to meet the needs of efficient production and quality products. Yugong is able to provide high-quality, reliable construction machinery products.
Sales market
Our machines have been exported to many countries, including United States, Canada, Germany, France, United Kingdom, Greece, Netherlands, Italy, Brazil, Mexico, Argentina, Saudi Arabia, United Arab Emirates, etc.
Types of Water Drilling Machine
Rotary drilling rigs
Rotary drilling rigs are water drilling machines that use rotation to cut through the ground. They have a stable base, a power system, a control system, and a rotating drilling system with drill pipes and bits. The types of rotary drilling rigs include surface rotary drilling rigs, underground rotary drilling rigs, versatile rotary drilling rigs, and hydraulic rotary drilling rigs.
Direct push drilling machine
A direct push drilling machine is a water drilling machine that pushes a hollow rod into the ground. It uses little to no soil cutting, making it ideal for shallow groundwater extraction. It works by pushing the preloaded drill string into the soil using a push cart, mounted frame, or drill rig. Once the rod reaches the target depth, the well construction and groundwater sampling take place.
Air drilling machine
The air drilling machine is a type of water drilling machine that uses compressed air to cool and remove cuttings from the well. The air drilling machine can be used for boring holes of various diameters and depths. This machine has some advantages over traditional water-based drilling methods, such as faster drilling speeds and fewer mud-related issues. However, it requires a high-pressure air source, usually a large portable air compressor.
Auger drilling machine
The auger drilling machine is a water drilling machine that drills holes by rotating and extracting soil with a specially designed screw-shaped tool called an auger. The auger can be pushed into the soil as it rotates, bringing the excavated material up and out of the hole through the spiral flights.
Product Parameters
|
Model |
YG-200 |
YG-300 |
YG-400 |
YG-600 |
|
Weight(Ton) |
5.5 |
9 |
10 |
12 |
|
Drilling Diameter(mm) |
140~305 |
140~325 |
140~350 |
140~350 |
|
Drilling Depth(mm) |
200 |
300 |
400 |
600 |
|
Walking Speed(Km/h) |
2.5 |
2.5 |
2.5 |
2.5 |
|
Climbing Angles |
30 |
30 |
30 |
30 |
|
Power(Kw) |
65 |
84 |
95 |
115 |
|
Pressure(Mpa) |
1.7~3.0 |
1.7~3.3 |
1.7~3.5 |
1.7~3.5 |
|
Air Consumption(m³/Min) |
17~30 |
17~35 |
17~35 |
17~35 |
|
Drilling Pipe Diameter(mm) |
76/89/102 |
89/102 |
76/89/102 |
76/89/102 |
|
Drilling Pipe Length(M) |
1.5/2.0/3.0 |
1.5/2.0/3.0 |
1.5/2.0/3.0 |
1.5/2.0/3.0 |
|
Rig Lifting Force(T) |
18 |
28 |
24 |
30 |
|
Swing Speed(Rpm) |
50~70 |
55~115 |
45~115 |
45~115 |
|
Swing Torque(N.M) |
5000~6500 |
7200~9500 |
8500~10000 |
8500~10500 |
|
Dimension(m) |
3.8*1.7*2.35 |
5.5*1.95*2.78 |
5.2*2*2.78 |
5.4*2.1*2.85 |
Application of Water Drilling Machine
Creating a water source
Water drilling machines create wells as a permanent water source at home or offices. This is especially important in areas with dry weather or frequent water shortages. The wells provide convenient access to groundwater, which is important for domestic use, irrigation or industrial processes.
Conducting hydrogeological studies
Geologists, environmental scientists or engineers often use water drilling machines during hydrogeological studies to understand groundwater flow, aquifer properties or water quality. Such studies help determine the best areas to place wells for constant water flow.
Undertaking environmental remediation
Groundwater monitoring and environmental cleanup are made easier by using water drilling machines. They accurately place monitoring wells or extraction points through precise drilling. Therefore, environmental pollution is significantly reduced and geological formations are precisely studied.
Irrigation systems in agriculture
The durability of agricultural irrigation systems relies heavily on water drilling machines. These machines are used to create deep wells and efficient drip or sprinkler irrigation systems. Agriculture can become more resilient by providing farmers with a dependable water source even in dry seasons.
